Timely repair of concrete structures

We provide a recommendation on the repair urgency of concrete structures and help our customers decreasing corrosion costs.

Our vision

We provide continuous corrosion diagnosis and forecast in reinforced concrete structures to help our customers decreasing corrosion costs and ensure safety.

Our technology

Our solution combines:

  • wireless embedded sensors
  • data analysis
  • data interpretation and recommendation on repair urgency.

Case studies

Our solution has been implemented in three projects: Two new concrete structures and one existing structure being repaired.

Team members

Completed projects

Planned projects

CHF funding

Our vision

Reinforced concrete is widely used in large infrastructures tunnels, garages, bridges, etc.) and in many public and private buildings. However, the service life of reinforced concrete structures is often limited due to corrosion of the steel reinforcement. Concrete structures suffering from corrosion have to be repaired in order to reach their expected service life but there is currently a lack of knowledge to determine the right time of repair. This results in:

  • Foregone revenues due to a too early repair of the structure
  • Compromised safety if repair is not timely performed which ultimately endanger human life

With our solution, we aim at obtaining continuous reliable corrosion diagnosis and forecast, which can be usedboth for structures built with traditional Portland Cement but also containing new blended cements. With our solution, we can help our customers selecting the right type of repair, for the right structure at the right time.

Our solution enables decreasing the number of structures needing repair simultaneously and thus helps diminishing corrosion costs while ensuring safety.

Decreased
corrosion costs

Improved
safety

Continuous monitoring

Suitable for new blended cements

Team

Coming soon...



More than a sensor: a complete solution

Ours is a complete solution that integrates:

  • Wireless sensors
  • Data analysis
  • Data interpretation

Our sensors permit monitoring all relevant parameters for corrosion and durability. From the sensor response, we  perform a holistic interpretation of the data. As a result, we obtain reliable corrosion diagnosis and forecast. With this information, we provide a recommendation on the repair urgency at the different locations in the concrete structure where our sensors are embedded.

more than a sensor

The sensor

Our solution is an embeddable multifunctional sensors in selected representative locations in concrete structures. It can be used in:

  • New concrete structures
  • Existing (corroding) concrete structures
  • Concrete structures undergoing repair

Each embedded multifunctional sensor is composed of individual sensors, which respond to different parameters. Altogether, our multifunctional sensor permits, for the first time, the continuous long-term monitoring (at different depths from the concrete surface) of all relevant parameters for corrosion and durability: pH, chloride concentration, temperature, concrete’s electrical resistance, steel potential.

The sensor is coupled with a measuring unit to perform the required measurements and it transmits the data wireless thanks to the LoRa technology.

Data analysis

From the transmitted sensor responses (thanks to the LoRa technology), we perform a holistic interpretation of the data by considering the interaction of all measured parameters. As a result, we obtain:

  • Profiles (and their forecast) of all relevant parameters for corrosion and durability (pH, chloride concentration, temperature, concrete’s electrical resistance, steel potential)
  • Reliable corrosion diagnosis and forecast

Our analysis is continuously refined as we obtain more data so we can obtain more and more accurate results.

Data interpretation

From the analysed data, we provide our customers a service based on a recommendation on the repair urgency at the different locations in the concrete structure where our sensors are embedded. An example of the information our customers obtain with this service can be seen with the following clickable demo.

Case studies

Bridge in Santa Clara
(Cuba)

Bicycle garage in Bludenz (Austria)

bludenz garage

Parking garage in Saas-Fee
(Switzerland)
